Engine
| Type | Four stroke, parallel twin cylinder, DOHC |
| Cooling system | Liquid cooling |
| Cylinder capacity | 647 cc / 38.5 cub. inch |
| Engine crank angle | 270° Parallel twin. |
| Bore x stroke | 79 x 66 mm / 3.1 x 2.6 inches |
| Compression ratio. | 11.6:1 |
| Valve drive | Double Overhead Cams / Twin Cam (DOHC) |
| Number of valves | 4 Valves per cylinder. (2x in and 2x out) |
| Valve Intake / exhaust | Ø 31.5 mm / 27.1 mm |
| Valve clearance (cold engine max 35°C) | Inlet 0,20 mm +/- 0.04 mm, Outlet 0,28 mm +/- 0.04 mm |
| Ignition | BMS-E digital engine management |
| Spark plugs | 2x NGK LMAR8D-J or 2x NGK LMAR8AI-8 (Iridium) |
| Electrode Gap | 0,7-0,9 mm |
| Starter | Electric |
| Gasoline supply | Fuel injection BMS-E, 38mm Throttle valve |
| Fuel pressure | 1.5 Bar (+ 1.5 bar, -0.5 bar) |
| Maximum power | 44 kw / 60 hp @ 7.500 rpm |
| Fuel type | Premium unleaded (95 RON) max. 10% ethanol |
| Fuel consumption | 4.40 litres/100 km (22.7 km/l) |
| Torque | 66 Nm @ 6.000 rpm / 48.7 lb-ft @ 6.000 rpm |
| Emission details | Closed-loop three-way catalytic converter, emission standard EU-4 |
Electical system
| Alternator | Three-phase 580 W generator |
| Battery | 12 V / 12 Ah, maintenance-free battery |
| Headlight | Low-/high beam: Halogen12V/55W |
| Rear light | Brake-/rear light: LED |
| Starter | 600 Watt |
Transmission
| Transmission | CVT (Continuously Variable Transmission) |
| Final reduction | Belt |
| Belt specifications | Length 894mm, Thick 32,4mm, Angle 28°, Tooth 16,9mm (OEM BMW 24827729767) |
| Belt replacement | Mitsuboshi Transmission Belt MBLSC105 |
| Clutch | Centrifugal clutch |
| Final drive | Chain drive in oil bath |
| Final drive ratio | 1,688:1 |
| Variator rollers | 30×20/8-33 grams (8 pieces) |
| Dimensions rollers | Height: 30 mm Width: 20 mm |
| Weight rollers | 33 Grams |
Chassis
| Frame | Steel tube construction with aluminium die cast unit |
| Wheelbase | 1591 mm / 62.6 inch |
| Head tube angle | 25.4° |
| Wheel castor | 92 mm / 3.6 inch |
| Front suspension | System Upside down fork Ø 40 mm / 1.6 inch |
| Steering angle of movement | Left 64.6° / Right 64.6° |
| Rear suspension | System Cast single swingarm |
| Front suspension travel | 115mm / 4.5 inch |
| Rear suspension travel | 115mm / 4.5 inch |
| Front brake | Double floating 270mm discs, 2 piston caliper, ABS |
| Rear brake | Single floating 250mm disc, 2 piston caliper, ABS |
| Front wheel material | Aluminium cast |
| Rear wheel material | Aluminium cast |
| Front carrying details and capacity | Two compartments incl. 12 volt outlet |
| Rear carrying details and capacity | Underseat compartment (two full-face helmets) |
| Seat (Standard seat with heating) | Seat height: 805 mm, step length: 1,910 mm |
| Seat (Low seat without heating) | Seat height: 785 mm, step length: 1,855 mm |
Tyres
| Front wheel | 3.50 x 15 inch |
| Rear wheel | 4.50 x 15 inch |
| Front tire | 120/70 15 inch |
| Front tire speed rating | 56H |
| Tube / Tubeless | Tubeless |
| Full specification front tire | 120/70 R 15 M/C 56H TL (Metzeler) |
| Tire pressure front | 2,3 Bar |
| Balance weight front wheel (max.) | 80 gram |
| Rear tire | 160/60 15 inch |
| Rear tire speed rating | 67H |
| Tube / Tubeless | Tubeless |
| Full specification rear tire | 160/60 R 15 M/C 67H TL (Metzeler) |
| Tire pressure Rear | 2,5 BAR (2,9 Bar with passenger) |
| Balance weight rear wheel (max.) | 80 gram |
Lubrication
| Enigine oil | BMW Synthetic Advantec 15W50 Engine Oil |
| Amount of Engine oil (refill) | 2.8 litres |
| Amount of Engine oil (including oilfilter change) | 3.1 litres |
| Oil level difference between MIN and MAX | 0,5 litres |
| Oil filter | BMW Oil Filter PartNo. 11427673541 |
| Oil pressure at idle | 1.5 Bar (+ 1.5 bar, -0.5 bar) |
| Oil pressure at 3.500 rpm | 4.5 Bar (+ 1.5 bar, -1.5 bar) |
| Lubrication | Dry sump |
| Final drive oil | 75W-90 SYN |
| Amount of final drive oil | 500 ml |
| Gearbox oil | 75W-90 SYN |
| Amount of Gearbox oil | 250 ml |
Suspension
| Front suspension type | System Upside down fork Ø 40 mm / 1.6 inch |
| Type suspension oil | SAE 7,5 |
| Amount of suspension oil | 390 ml |
| Front suspension size | 40 mm |
| Front suspension travel | 115mm / 4.5 inch |
| Adjustable front fork preload | No |
| Adjustable front rebound damping | No |
| Central front strut | No |
| Steering damper | No |
| Rear suspension type | Double-sided swivel arm |
| Rear suspension travel | 115 mm / 4.5 inch |
| Rear adjustable spring preload | Yes |
| Adjustable rear rebound damping | No |
| Number of rear shock absorbers | 1 |
| Rear suspension material | Aluminum / Steel |
Dimensions / Sizes / Contents
| Length | 2.218 mm / 87.3 inch |
| Width | 916 mm / 36.1 inch (incl. mirrors) |
| Height | 1.411 mm / 55.6 inch |
| Wheelbase | 1.595 mm / 62.6 inch |
| Saddle height | 805 mm / 31.7 inch |
| Ground clearance | 130 mm |
| Dry weight | 249 kg / 548 lbs |
| Wet weight | 261 kg / 575 lbs |
| Maximum permissible weight | 445 kg / 981 lbs |
| Tank capacity | 16 litres / 4.23 US gallons |
| Reserve fuel capacity | 3 litres / 0.8 US gallons |
| Stand Type | Center / Kick |
Instrumentaria
| Digital instrumentation | Yes, analog and digital. |
| Clock | Yes (12/24 o’clock indication) |
| Tachometer | Yes |
| Trip Odometer | 3x (Trip A and trip B, day trip with autoreset) |
| Oil pressure gauge | No |
| Speedometer | Analog (km/hour) |
| Engine temperature indication | No |
| Fuel level type | 7 segments indicator |
Facts
| Acceleration 0-100 km/uur | 7.5 seconds |
| Color options | Frozen Bronze Metallic, BlackStorm Metallic, LightWhite |
| Drivers license | Driving license A (Unlimited power) |
| Generic Type (Primary) | Touring Scooter |
| Guarantee | 3 years |
| Model Introduction Year | 2016 |
| First Model Introduction Year | 2012 |
| Number of seats | 2 |
| Speed Governor | No |
| Top speed | 180 km/hour / 111.8 mph |
| Recommended retail price NL | €13.400,- |
| Recommended retail price BE | €12.300,- |
Tightening torques
| Air intake stub to cylinder head | 10 Nm (M6 x 20) |
| Camshaft bearing cap to cylinder head | 10 Nm (M6 x 35 and M6 x 60) |
| Clamping screws in telescopic forks | 8 Nm (M6 x 30) |
| Cylinder head cover to cylinder head | 10 Nm (M6) |
| Fork leg to bottom fork bridge | 19 Nm (M8 x 25) |
| Gearbox oil drain plug | 28 Nm (M16 x 1.5) |
| Gearbox oil filler plug | 28 Nm (M16 x 1.5) |
| Oil drain plug in crankcase | 28 Nm (M16 x 1.5) |
| Oil filter adapter to crankcase | 35 Nm (M20 x 1.5) |
| Oil filter to engine | 11 Nm |
| Rear wheel | 60 Nm (5x M10 x 1,25 x 40) |
| Silencer to Bracket | 19 Nm (M8 x 30) |
| Silencer to front silencer | 19 Nm (M8 x 30) |
| Silencer cover to silencer | 8 Nm (M6 x 16) |


by Daniel Arsenault (www.doubleclutch.ca)
Published August 24, 2016
The 2016 BMW C650 GT (short for “Gran Turismo”) is not your typical scooter. There’s something magical about it that makes this high capacity maxi-scooter above par for conventional standards. Right off the bat, the C650GT grabbed my attention as it doesn’t look like any scooter I’ve ever seen. With its sporty styling and modern design, it’s definitely raising the bar for the scooter market. The 2016 model has several new design changes that were derived from the automotive side of BMW – this adds to the overall appeal.
I really enjoyed riding this scooter – it’s extremely comfortable, well-balanced, and at 650cc it has plenty of punch that’s sure enough to leave most cars behind. With a sticker price of $12,285 it may catch most by surprise as it seems expensive for a scooter. When factoring in what you actually get for that, such as heated grips, heated seats, tire pressure monitoring, a full warranty and roadside assistance, one can easily start to justify the price tag that comes with this luxury two-wheeler.
The C650 GT has a ton of storage both under the seats, as well as built into the front fairing. Two things I noted about the storage is that only the front left storage compartment is lockable and that is achieved by locking the steering to the left. This renders the right side unlockable, which can be a bit annoying. The trunk has a built-in LED, which I found to be extremely helpful when getting my belongings out in the dark. One last thing to note about the storage is that the C650 GT features the largest storage in its class, with the ability to store two full-face helmets.
A few of the additional standard features included on the C650GT are ABS, automatic stability control, electronically adjustable windshield, as well as an automatic parking brake that engages when the side stand is lowered. With a plethora of options available from BMW, such as a smart phone cradle, storage rack, storage pod for the rear or storage bag for the center between your legs, navigation and communication as well as many more, there’s sure to be a combination of options that are sure to suit your specific needs.
The CVT transmission is extremely smooth, making “shifts” seamless – this adds to the overall comfort. With a wet weight of 575 pounds, the C650GT isn’t light nor is it small by any means, but none of that seems to matter. Thanks to the low center of gravity and CVT gearbox, it’s effortless to maintain balance at low speeds. Even with a passenger, you can practically stand still on the spot. Braking is sufficient with its twin rotor 270mm dual piston front calipers paired with factory ABS.
Highway speeds were effortless to achieve and maneuvering through traffic was just as effortless. One thing I noted during my time with the C650GT was how smooth the transition from braking to acceleration through corners and bends was. There is no jerky transition that catches you off-guard whether you feather the throttle or roll into it hard so you can corner with confidence.
Comfort was not overlooked when BMW designed the C650GT. The rider has several options when it comes to foot placement, whether legs are stretched out or kept back for a more aggressive riding position. The rider’s backrest is very comfortable, it keeps you in your spot when you’re under hard acceleration, and the “GT” stitching is a tasteful touch. A massive passenger seat renders the passenger just as coddled, its hand-holds are very sturdy and ride height is in a well-positioned spot giving a nice field of view over the rider, while maintaining adequate wind shielding. The only problem with passenger comfort was the lack of a passenger back rest, which is a must-have option in my head.
One funny quirk that kept catching me off-guard was the starting procedure. The bike will not start if the kickstand is down or the brake lever isn’t pressed. It took a minute of confusion on more than one occasion before figuring out why the bike wouldn’t turn over. The engine is a little louder than I would have expected, and the exhaust is newly designed for 2016 with a nice note. The heated grips and seats seemed like a bit more of a novelty than anything to me, as I tend to only ride during warm weather, but riding after dark, and going through low valleys where the temperature drops, they were a much-appreciated feature that left both my passenger and I comfortable.
Comfort and quality come together to make the 2016 BMW C650GT a very well rounded maxi-scooter. Perhaps scooters won’t be as popular in North America as in Europe, but the C650GT is definitely paving the way when it comes to a comfortable mode of transportation. If you’re in the market for a large capacity scooter, or even a touring motorcycle, I’d give the C650GT a look – it may just win you over.

BMW achtte in 2012 de tijd rijp om met de C 600 Sport en de C 650 GT twee modellen te lanceren die zieltjes moesten winnen in het segment van de maxiscooters. Eigenaardig genoeg had de C 600 Sport hetzelfde blok als de C 650 GT, een anomalie die in 2016 na een fikse update werd rechtgezet.
